Selective soldering is replacing hand soldering, where a small number of through-hole components are fitted to an electronic sub-assembly. In the process, either the assembly is moved to the mini solder wave to make the joint, or the wave is moved to the assembly.

Application Need

Users of the selective soldering process have to profile the process at time of setup, and then at frequent intervals to measure process stability. The biggest challenge is to find enough space into which the thermal profiler can be positioned.

Benefits to the customer

Ensure and prove that solder profile specifications are met
Fine-tune the process to maximize throughput
Troubleshoot the process quickly and easily
Measure and track process stability

Datapaq® SelectivePaq Thermal Profiling System

Smallest thermal profiler in the electronics industry for easy fit in the process
Rechargeable and always ready for use (fast charge and eady to use again in just 5 minutes)
Rugged case and connector design ensures trouble-free use
